1.0-Ton Electric Forklift
It is a versatile industrial special equipment that integrates loading and unloading, stacking, and short-distance transfer operations. It serves as a core material handling device in modern warehousing, manufacturing, and logistics industries. Relying on the front-end elevating forks in conjunction with a hydraulic system, it completes cargo lifting, stacking, and transfer operations, significantly replacing manual handling and enhancing warehouse circulation efficiency.
tummy-gm@chengchivehicle.com
+86 18866611248
Contact Us

Product Display

1.0-Ton Electric Forklift

Product Parameters

ParameterValue
Rated Load Capacity (kg)1000
Mast Lifting Height (mm)3000
Load Center Distance500
Ground Clearance of Forks After Lowering (mm)90
Turning Radius (mm)1550
Minimum Right Angle Aisle Width (mm)1800
Mast Static Height (mm)2000
Overall Body Length (mm)1950
Overall Body Width (mm)980
Maximum Fork Spacing (mm)920
Maximum Height During Operation (mm)3750
Fork Dimensions (L×W×H) (mm)980*100*30
Minimum Fork Width (mm)300
Lifting Speed (Loaded/Unloaded) (mm/s)160/190
Travel Speed (Loaded/Unloaded) (km/h)12/13
Maximum Gradeability (Loaded/Unloaded)10/12
Tire TypePneumatic & Solid Tires
Front Wheel Size (mm)500-8
Rear Wheel Size (mm)500-8
Overall Machine Weight (kg)1520
Operation TypeSit-down Type
Steering TypeHydraulic Power Assist
Wheelbase (mm)1700
Wheel Track (Front/Rear) (mm)850/800
Charging Input Voltage (V)220
Rated Voltage (V)60
Battery Capacity (Ah)180Ah×5
Lifting Motor (kW)3.0
Drive Motor (kW)3.0
Power TypeBattery
Per Charging Cycle8/10


Packaging And Transportation

faq

What kind of payment method can I choose?

(1) L/C 100% at sight
(2) T/T (30% as deposit before production and 70% as balance before shippment)
(3) Other payment methods can be negotiated

What is the shipping method and time?

Ro-ro, deck, frame, shipping time depends on shipping company

Can You Supply The Spare Parts Of This Truck Trailer?

Yes, We can supply the spare parts for all the truck trailers we selling. We have spare parts department professional for this. Once you need spare parts we can supply immediately.

Can You Satisfy My Special Requirement?

Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity! And we think about customer's demands considerately, provide professional trailer designed solutions.

Are you a factory or a distributor?

We are a factory with 15 years of export experience

How to guarantee truck quality?

There is a one-year warranty, and all parts are inspected.
